The PTO Link® HD System is our most versatile model. It’s designed for heavy duty applications with compact or utility tractors rated from
35 HP up to 130 HP (engine net), and with most 3-point hitch or pull behind (drawbar) implements. PTO Link
® is the original, universal PTO quick-connect system consisting of two interconnecting steel couplers. Its patented Open-Plate
™ system replaces the traditional spline-to-driveline connection with a visible interface design that’s both easy to see and reach. Now you can quickly and safely connect / disconnect implements at the tractor’s PTO in just seconds! A complete PTO Link
® System requires both a Tractor (Female) Coupler and an Implement (Male) Coupler. For best results, every tractor should be equipped with a Tractor Coupler, and every power-driven implement should be equipped with an Implement Coupler.
The PTO Link® System adds 5 inches to the implement’s driveline. See more descriptions, product features and safety information below.
PTO Link
® is the original, universal PTO quick-connect system consisting of two interconnecting couplers. Its patented Open-Plate
™ system replaces the traditional spline-to-driveline connection with a visible interface design that’s both easy to see and reach. Now you can quickly and safely connect / disconnect implements at the tractor’s PTO in just seconds! A complete PTO Link
® System requires both this Tractor (Female) Coupler and an Implement (Male) Coupler.
For best results, every tractor should be equipped with a Tractor Coupler, and every implement should be equipped with an Implement Coupler. See more descriptions, product features and safety information below.
Designed for:
- Any compact or utility tractor (from 35 HP up to 130 HP) with Category 1 or 2 implements
- Any pull-behind implements, including flex-wing or batwing rotary cutters
- Tractor owners who operate in a rough environment.
- Standard PTO spline length (3″ and longer)
- High Torque (>650 ft.lbs) scenarios or with heavy duty implements (e.g., stump grinders, balers, augers, flail mowers, water pumps, large tillers) where reverse torque is common
Note: The HD System adds 5 inches to the implement’s driveline. See driveline measurement instructional video and
FAQ #5 and #6 for more information.
NOTICE: In rare situations, certain pull-behind implements with
two separate sections of a single driveline and a universal or CV joint located at a midway point on the driveline between the primary PTO connection and a single gearbox (as shown), may not be compatible with the PTO Link system. If you have this type of implement, please see
FAQ #17 for more information on compatibility or if you have further questions, please call us at 833-444-5465, ext 1.
For safety, the female or male mating coupler components of the HD System are
NOT compatible nor interchangeable with the SD or Compact Systems!
